Amplifier Features:
 The use of H-line high and low voltage power supply technology, the full models using the domestic advanced 4-layer circuit boards and 6-layer circuit board laminating production technology, the line design is more optimized and simpler than the traditional power amplifier to improve work efficiency 30% higher conversion rate , Functional loss, more green.
 Up to 12 reasonable line protection design, all-round protection from the amplifier and speaker speaker unit divider, etc., to match any speaker can be perfect.
 Sound clean and sleek, sweet high-frequency transparent, low-frequency dynamic good explosive strong relaxation.

 Many models, improve product lines, covering most of the power amplifier power models can be used.
 Improve and facilitate after-sales service system, long-term free after-sales service, protect the interests of all users.

Unique amplifier tone ratio and sensitivity adjustment function
110dB signal noise than the full range of 2U fuselage height
1500 strong damping characteristics of the largest 2600W / 8ΩX2
 100V / Us slew rate precision SMD manufacturing process
 Multi-channel optional with full-featured soft protection circuit

Nine new technology applications:
Power - to - weight ratio limit zero thermal barrier cooling scheme system temperature segment analysis
 Power - volume ratio limit Zero - thermal path difference crystal arrangement High - frequency energy cumulative analysis
 Accurate energy ratio online load resistance detection output cumulative adjustment analysis

Features:
Set the front panel bridge, stereo, and then work mode LED finger lights
 Rear panel set bridging, stereo, and then working mode adjustable switch and recoverable power protection
 Power-on inrush current limit
 The system gain can be set to 0.775V 1V 1.5V
The application of high-end technology for the stability of the system to provide a solid guarantee of confidence:
Reasonable structural optimization: excellent power devices with, and tailor-made cooling system for them, into the design concept of zero thermal resistance, a reasonable power supply program, multi-layer precision circuit board with excellent SMT manufacturing process, the whole machine Power density increased dramatically, reducing the volume of the machine, the performance is also a qualitative leap;
 Real-time temperature sensing conduction technology applications: simultaneous detection of power devices and transformers temperature, real-time reaction cooling system, real-time system to provide high-quality cooling services;
 Temperature - Power Control Technology Applications: When the system abnormal temperature is too high, the appropriate automatic attenuation of output power, to achieve the power --- temperature balance, and light panel temperature warning lights to avoid accidents caused by abnormal;
 Real-time load detection technology: the system has a more reasonable system protection, when the load is less than the set ＆#118alue, the system will automatically implement the soft protection, when the exception is removed, the output can be back to normal immediately;
 Real-time high-frequency energy output detection technology Applications: Prevent accidental abnormal high-frequency signals on the speaker damage, when the cumulative high-frequency output reaches the set system startup time, the detection system can automatically decay the power output to a safe voltage Range, while the normal music signal can be smooth, without any loss;
 Real-time distortion control technology applications: to avoid the signal is too large, the output signal serious stripping damage to the speaker when the input signal due to improper operation or other abnormalities is too large, the system can peak in the output reaches the input signal automatically Amplitude limit

Technical specifications
 power supply
 Universal switching mode power supply, up to 400V AC, with power correction
 Patented output filter with ripple cancellation reduces AC inrush current,

protection
 Comprehensive protection circuit:
 AC Protection: Turn off the power when the AC power supply voltage is outside the operating range
 Clip Limiter: Prevents severe clipping of the waveform from reaching the speaker while maintaining full peak power output
 DC protection: to prevent the infrasound signal output
 Vhf Protection: Prevents strong non-musical high-frequency signals from reaching the speakers
 Short circuit protection: automatic protection reset function to prevent the amplifier short circuit, or output circuit other stress failure
 Long-Term Limiter: Stable, long-term RMS (non-audio) signals that prevent maximum output from reaching the speaker
 Thermal protection: Output stage operating temperature up to 80 ° C (176 ° F)
Temperature-controlled continuous variable speed fan, air flow from front to back

conventional
 Fixed frequency switching mode output stage for high-quality sound accuracy
 All models are 2 rack unit sizes, saving rack costs and space
 Light weight for easy rack installation and shipping
 Standard Phoenix connector: for analog and digital input, audio output, auxiliary power supply, sirens and universal input and output

Speaker system configuration
 Direct drive low impedance load or 70V / 100V high impedance distributed circuit
 Each channel has a switchable 35Hz / 70Hz high-pass filter
 Can be mixed with low resistance and high resistance system configuration
 Each pair of bridge channels is low impedance

Line signal processing
 Top line signal processing, high dynamic range, rich functionality
 Define the output FIR filter
 Active Damping Control technology for cable compensation
 Power limiter (TruePower ?, voltage rms, rms current) + peak limiter
